Plastim

Fan with filter, 125 (175) m3/h, 210x210, 230V 50/60Hz IP54 PTF2000 Plastim

In stock - 23 items available
SKU: PTF2000
€69,12 including VAT

Online payment by card - after completing the order you will be redirected to the payment gateway, payment confirmation will be sent to your email

Cash on delivery - payment according to the payment instructions will be made to the driver of the transport company

By transfer - you will receive an advance invoice to your email no later than the next working day, on which you will find the account number that you enter when making the payment.

By invoice - this payment option is available to partners who have signed a framework agreement with our company.

If you would like to use the last 2 methods, call our manager and he will give you instructions on how to receive an invoice with or without VAT.

The electrical equipment we supply meets high quality standards, has a 24-month warranty and meets all EU requirements.

In the event of a complaint, no fee is charged for returning the goods.

Ventilation grille with fan and filter, size 210x210 mm, for installation in electrical panel, automation cabinet, ATM or gaming terminal. PTF2000, manufacturer Plastim (Turkey)

Used for the intake of outside air in electrical cabinets, ATMs, payment terminals, gaming machines, automation cabinets, control panels, service stations. Usually installed on the side walls of the enclosures to maintain the IP rating.

  • External dimensions: 210x210x98 mm
  • Installation size: 175x175mm
  • Volume flow: 125 (175) m3/h
  • Noise level: 42 (46) dB(A)
  • Bearing: Ball bearing
  • Operating voltage: 220-230VAC, 50/60Hz
  • Current consumption: 0.14 (0.13) A
  • Rated power: 26 (23) W
  • Electrical connection: 3-pole terminal
  • Flow direction: From outside to inside (can be changed)
  • Operating temperature: -10/+70 °C
  • Protection rating: IP54
  • Plastic material: ABS UL94 V0 flame retardant
  • Sealing: Polyurethane sealing
  • Color: RAL 7035 (RAL 7032 on request)
  • Weight: 1.05 kg
  • Installation: Quick mounting

To ensure automatic air exchange and temperature maintenance with this fan, a simple bimetallic thermostat or a more complex temperature controller is required; both devices can be purchased on our website.
