1 12
Vendor: TENSE

Three-phase digital panel multimeter DIN Current, voltage, and frequency indicator

Barcode: EM-100DIN
€61,52
€61,52
excl. VAT: €51
15 in stock
Brand: 100A
  • Description
  • Instructions
  • Payment methods
  • Warranty

Multímetro de painel multifunções trifásico TENSE

Descrição

O multímetro digital trifásico TENSE é um medidor de painel multifunções concebido para monitorizar parâmetros eléctricos em sistemas trifásicos. O instrumento apresenta a tensão, a corrente e a frequência e permite a monitorização de fases individuais.

O multímetro foi concebido para ser montado numa calha DIN padrão de 35 mm.

Principais vantagens

  • Medição multifuncional de 4 grandezas:

    • Corrente (I)

    • Tensão (U) - L-L e L-N

    • Frequência (Hz)

  • Monitorização monofásica

  • Medição precisa com transformador de corrente

  • Transformador de medição incluído nos modelos EM-100DIN e EM-250DIN

  • Montagem fácil em calha DIN standard

Especificações técnicas

Parâmetros Valor
Gama de medição de corrente EM-06DIN: 5/5 ... 9995/5 A (medição indireta) EM-100DIN: 1 - 100 A EM-250DIN: 2 - 250 A
Gama de medição de tensão L-N: 1 - 300 V AC L-L: 1 - 500 V AC
Frequência 40 - 60 Hz
Instalação Calha DIN de 35 mm
Aplicações Redes trifásicas industriais e domésticas


Recomendações

  • Para uma medição exacta da corrente, recomendamos a utilização de transformadores de corrente compatíveis:
    60/5, 75/5, 100/5, 150/5, 200/5, 250/5, 300/5, 400/5, 500/5, 600/5, 800/5, 1000/5, 1500/5

  • Os transformadores podem ser adquiridos diretamente na nossa loja virtual.

Download

User Manual
